Real engineering challenges. Clearly documented solutions.

This page presents verified ALUFORMIX project stories covering new lines, individual equipment, downstream systems, automation and modernization. Each case study explains the customer’s challenge, the supplied scope, technical approach, execution and approved outcome.

Line layout & process flow

How a complete line arranges on the floor

Start with the general arrangement, then open the process flow to walk the twenty-one steps machine by machine.

General arrangement drawing of a complete ALUFORMIX aluminium extrusion line
  1. ALUFORMIX automatic extrusion log storage, charging and feeding system01Extrusion log storageOrganized receipt, buffering and feeding of logs.
  2. ALUFORMIX log loader and log pusher tables feeding an aluminium extrusion line02Log loader & pusherControlled movement from storage into the heating system.
  3. ALUFORMIX automatic extrusion log storage, charging and feeding system03Log / billet cleaningRemoval of surface contamination before heating and extrusion.
  4. ALUFORMIX log heating furnace with recirculation blower for aluminium billet preheating04Billet furnace / preheatingTemperature preparation matched to alloy and production plan.
  5. ALUFORMIX billet rest station with buffer rollers and pneumatic centering05Billet restManaged buffering and controlled presentation after heating or cutting.
  6. ALUFORMIX robotic billet loader cell combining billet shear, gauge, transfer, positioning pusher and robotic arm06Billet saw / shearAccurate billet-length preparation for the press cycle.
  7. ALUFORMIX robotic billet loader cell combining billet shear, gauge, transfer, positioning pusher and robotic arm07Billet transferSafe movement between cutting, buffering and press-side equipment.
  8. ALUFORMIX robotic billet loader cell combining billet shear, gauge, transfer, positioning pusher and robotic arm08Billet positionerAlignment and centering before final loading.
  9. ALUFORMIX robotic billet loader cell combining billet shear, gauge, transfer, positioning pusher and robotic arm09Robotic loaderRepeatable loading into the press zone.
  10. ALUFORMIX hydraulic aluminium extrusion press cylinder, columns and main ram10Extrusion pressControlled force and motion to form the required profile. 800 to 4,000 MT tonnage capacity, 4" to 10" billet diameter.
  11. ALUFORMIX intensive air quench system at the press exit of an aluminium extrusion line11Quenching systemAir, water or combined profile cooling according to process needs.
  12. ALUFORMIX puller with integrated puller saw on the extrusion run-out12Puller and puller sawGuided profile extraction and synchronized separation.
  13. ALUFORMIX lead out tables with puller railway track for aluminium profile extraction13Lead out tablesProfile support and controlled heat removal after extrusion.
  14. ALUFORMIX cooling and handling tables carrying extruded aluminium profiles14Cooling & handling tablesTransfer through cooling, accumulation and finishing stages.
  15. ALUFORMIX cooling and handling tables carrying extruded aluminium profiles15Stretchers with stretcher beamProfile straightening and controlled deformation.
  16. ALUFORMIX profile flying cut saw and clamping section on the extrusion line16Cutting tableFinal-length cutting for subsequent handling.
  17. ALUFORMIX cooling and handling tables carrying extruded aluminium profiles17Inspection tableAccessible presentation for visual and dimensional checks.
  18. ALUFORMIX cooling tables, overhead crane and automatic basket stacking logistics18Stacking systemLayer formation and protected profile placement.
  19. ALUFORMIX cooling tables, overhead crane and automatic basket stacking logistics19Basket conveyorsMovement of loaded and empty baskets through the plant.
  20. ALUFORMIX log heating furnace with recirculation blower for aluminium billet preheating20Ageing ovenHeat treatment for the specified temper and mechanical properties.
  21. ALUFORMIX APS automatic packaging system with robotic bundle transfer and ASRS automatic storage racks behind it21Packing systemProfile protection, bundle formation and wrapping.

Project documentation is being prepared for publication

ALUFORMIX project documentation is being prepared for publication. For a discussion relevant to your required equipment or application, contact our engineering team with the project scope and confidentiality requirements.

Request a Relevant Capability Discussion
Case-study format

What each published project will contain

  • Project title and country or region, where approved
  • Customer sector; customer name only with written permission
  • Press size, billet diameter and profile application, where non-confidential
  • Customer challenge, ALUFORMIX scope and key engineering features
  • Execution summary and measured outcome against an agreed baseline
  • Approved customer quote, photographs and video
Call WhatsApp Enquire
